MR-TMH250 is a compact film tape casting machine with vacuum chuck, which widely used in all kinds film coating research, like ceramic films, crystal films, lithium battery electrode coating, etc. It is designed with top cover heating, the heating temperature up to 150℃ adjustable and digital display.
Features
• Touch screen operation, high automation.
• Vacuum aluminium chuck is designed for quick suction of substrate.
• Built-in vacuum pump is designed.
• Coating stroke length can be set.
• Heating temperature up to 150℃ adjustable, and it's digital display.
Technical Parameters
| Working voltage | AC220V |
| Coating length | Max 250mm adjustable |
| Doctor blade | 100mm fixed width as standard, other size is optional |
| Coating thickness | 0.01~3.5mm adjustable |
| Vacuum chuck | L365 x W200 x H30mm |
| Vacuum pump | Built In Oil Free Vacuum Pump |
| Coating speed | 0~200mm/s adjustable |
| Heating method | Top cover heating |
| Heating temperature | RT~150℃ adjustable, digital display |
| Heating temperature accuracy | ±1℃ |
| Dimension | L500 x W310 x H330mm |
| Weight | 45kg |
Our Advantages
1. Steady and high quality ! -cause we are a manufacturer of Lithium Battery Equipment, and we only focus on one thing that is make professional Lithium ion Battery Equipment for customer around the world.
2. Friendly use! all MRBEST Battery Equipment with teach manual and support live teaching via media.
3. Reliable factory! My factory located in Shenzhen city of China, support factory visit and video factory visit .
4. 1 year warranty plus lifetime technical support.
5.All the parts use on machine, in stock forever.
6. Powerful technical support, NOT TRADE COMPANY! We are professional on Lithium Battery Equipment, the chief engineer team have
more than 20 years experience on lithium battery area, so we can easy do diagnose on machine if customer have question.
7. 100% PATIENCE to all customers! Our patience not only before consult order, also after-sale service, one by one .
